Kaishan LG Two-stage Compression Screw Air Compressor

Kaishan LG series two-stage compression screw air compressors adopt a working method of two-stage compression and inter-stage cooling, making the compression process closer to isothermal compression and significantly improving operating efficiency.
By reasonably distributing the compression ratio of each stage, the equipment effectively reduces the single-stage compression load and internal leakage, substantially enhancing volumetric efficiency. Meanwhile, the optimized bearing design reduces bearing load, operating noise, and vibration, ensuring high reliability while extending the service life of the air end, thus providing efficient and stable air supply support for industrial applications.
EMAIL US INQUIRY

开山LG系列两极压缩螺杆压缩机参数
开山LG系列两极压缩螺杆压缩机参数
Kaishan LG Two-Stage Compression Screw Air Compressor Specifications

型号 Model	排气压力(MPa) Working pressure	排气量(m³/min) Capacity	功率(kW) Power	排气接口 Outlet size	重量(kg) Weight	长(mm) Length	宽(mm) Width	高(mm) Height
KLT120-7	0.7	18.12	90	DN65	2000	2260	1440	1680
KLT120-8	0.8	17.95	90	DN65	2000	2260	1440	1680
KLT120-10	1.0	15.30	90	DN65	2000	2260	1440	1680
KLT150-7	0.7	21.80	110	DN65	2290	2230	1460	1840
KLT150-8	0.8	21.59	110	DN65	2290	2230	1460	1840
KLT150-10	1.0	17.77	110	DN65	2290	2230	1460	1840
KLT180-7	0.7	26.72	132	DN65	2350	2230	1460	1840
KLT180-8	0.8	26.46	132	DN65	2350	2230	1460	1840
KLT180-10	1.0	21.37	132	DN65	2350	2230	1460	1840
KLT215-7	0.7	31.75	160	DN80	3860	3060	1860	2050
KLT215-8	0.8	31.44	160	DN80	3860	3060	1860	2050
KLT215-10	1.0	25.91	160	DN80	3860	3060	1860	2050
KLT250-7	0.7	36.62	185	DN80	3900	3060	1860	2050
KLT250-8	0.8	36.26	185	DN80	3900	3060	1860	2050
KLT250-10	1.0	31.27	185	DN80	3900	3060	1860	2050
KLT270-7	0.7	41.00	200	DN80	3930	3060	1860	2050
KLT270-8	0.8	40.61	200	DN80	3930	3060	1860	2050
KLT270-10	1.0	32.95	200	DN80	3930	3060	1860	2050
KLT295-7	0.7	43.94	220	DN100	5100	3360	2100	2170
KLT295-8	0.8	43.51	220	DN100	5100	3360	2100	2170
KLT295-10	1.0	35.97	220	DN100	5100	3360	2100	2170
KLT335-7	0.7	49.57	250	DN100	5700	3360	2100	2170
KLT335-8	0.8	49.08	250	DN100	5700	3360	2100	2170
KLT335-10	1.0	40.18	250	DN100	5700	3360	2100	2170
KLT375-7	0.7	55.19	280	DN125	6350	3660	2260	2325
KLT375-8	0.8	54.65	280	DN125	6350	3660	2260	2325
KLT375-10	1.0	46.03	280	DN125	6350	3660	2260	2325
KLT420-7	0.7	62.46	315	DN125	6450	3660	2260	2325
KLT420-8	0.8	61.85	315	DN125	6450	3660	2260	2325
KLT420-10	1.0	54.08	315	DN125	6450	3660	2260	2325
KLT475-7	0.7	70.24	355	DN125	6540	3660	2260	2325
KLT475-8	0.8	69.55	355	DN125	6540	3660	2260	2325
KLT475-10	1.0	61.21	355	DN125	6540	3660	2260	2325
