  • Kaishan JN Series High Pressure Screw Air Compressor

Kaishan JN Series High Pressure Screw Air Compressor

  • This type air compressor is designed according to 40 bar maximum pressure.
    Rotor profile: SKY 2G Patented rotor profile with highest efficiency.
    Two stage compression: flexible design is corresponding to the lift valve,
    which has obtained global patent for invention.
    It is with heavy duty design, SKF bearing, connected to the drive directly
    without gear noise.
    The air compressor has optimum structure and maximum reliability.
  • EMAIL US   INQUIRY

Specifications of JN Series High Pressure Screw Air Compressor

 Model

PressureMpa)

Capacity(m3/min)

Motor Power(KW)

Dimensions(MM)

JN200-25

2.5

20

200

3760×2260×2260

JN200-35

3.5

16

200

3760×2260×2260

JN250-25

2.5

26

250

3760×2260×2260

JN250-35

3.5

21

250

3760×2260×2260

JN315-25

2.5

31

315

3760×2260×2260

JN315-35

3.5

26

315

3760×2260×2260

JN400-25

2.5

39

400

3760×2260×2260

JN400-35

3.5

32

400

3760×2260×2260
